Quick Overview
- 1#1: EPLAN Electric P8 - Industry-leading software for electrical schematic design, automated panel layout, and 3D wiring routing.
- 2#2: Zuken E3.series - Comprehensive CAE system for electrical and fluid schematics, 3D panel design, and automated manufacturing outputs.
- 3#3: SOLIDWORKS Electrical - Integrated electrical schematic and 3D panel modeling tool that syncs with SOLIDWORKS mechanical design.
- 4#4: SEE Electrical - Intuitive electrical CAD software for schematics, terminal strips, and intelligent panel layouts with strong automation.
- 5#5: AutoCAD Electrical - Electrical toolset for AutoCAD providing automated wire numbering, component libraries, and panel layouts.
- 6#6: Elecdes Design Suite - Multi-discipline electrical CAD with Paneldes for 3D routing, wire calculation, and manufacturing reports.
- 7#7: WSCAD ELECTRIX - Electrical CAD suite for automation design featuring macros, error checking, and 3D panel visualization.
- 8#8: PCSCHEMATIC Automation - Danish electrical design software optimized for panel building with intelligent symbols and project navigation.
- 9#9: Siemens Capital Electrical Designer - Advanced tool for complex electrical harnesses, formboard design, and panel integration in aerospace and automotive.
- 10#10: AVEVA Electrical - Integrated engineering software for instrumentation, cable management, and panel design in plant projects.
Ranked based on robust feature sets (schematic design, 3D modeling, automation), proven reliability, intuitive interfaces, and alignment with professional needs, ensuring both technical excellence and practical value for panel building workflows.
Comparison Table
This comparison table explores leading panel building software tools, including EPLAN Electric P8, Zuken E3.series, SOLIDWORKS Electrical, SEE Electrical, AutoCAD Electrical, and more, to assist users in evaluating options. Readers will discover key features, usability, and practical fit for their specific panel design and engineering needs.
| # | Tool | Category | Overall | Features | Ease of Use | Value |
|---|---|---|---|---|---|---|
| 1 | EPLAN Electric P8 Industry-leading software for electrical schematic design, automated panel layout, and 3D wiring routing. | enterprise | 9.7/10 | 9.9/10 | 8.2/10 | 8.8/10 |
| 2 | Zuken E3.series Comprehensive CAE system for electrical and fluid schematics, 3D panel design, and automated manufacturing outputs. | enterprise | 9.1/10 | 9.6/10 | 7.4/10 | 8.3/10 |
| 3 | SOLIDWORKS Electrical Integrated electrical schematic and 3D panel modeling tool that syncs with SOLIDWORKS mechanical design. | enterprise | 8.7/10 | 9.2/10 | 7.5/10 | 8.0/10 |
| 4 | SEE Electrical Intuitive electrical CAD software for schematics, terminal strips, and intelligent panel layouts with strong automation. | specialized | 8.7/10 | 9.2/10 | 7.8/10 | 8.1/10 |
| 5 | AutoCAD Electrical Electrical toolset for AutoCAD providing automated wire numbering, component libraries, and panel layouts. | enterprise | 8.4/10 | 9.2/10 | 7.1/10 | 7.8/10 |
| 6 | Elecdes Design Suite Multi-discipline electrical CAD with Paneldes for 3D routing, wire calculation, and manufacturing reports. | specialized | 8.2/10 | 9.1/10 | 6.8/10 | 7.6/10 |
| 7 | WSCAD ELECTRIX Electrical CAD suite for automation design featuring macros, error checking, and 3D panel visualization. | specialized | 8.1/10 | 8.6/10 | 7.4/10 | 7.8/10 |
| 8 | PCSCHEMATIC Automation Danish electrical design software optimized for panel building with intelligent symbols and project navigation. | specialized | 7.6/10 | 8.2/10 | 6.9/10 | 7.3/10 |
| 9 | Siemens Capital Electrical Designer Advanced tool for complex electrical harnesses, formboard design, and panel integration in aerospace and automotive. | enterprise | 8.2/10 | 9.1/10 | 7.4/10 | 7.8/10 |
| 10 | AVEVA Electrical Integrated engineering software for instrumentation, cable management, and panel design in plant projects. | enterprise | 8.0/10 | 9.0/10 | 6.5/10 | 7.2/10 |
Industry-leading software for electrical schematic design, automated panel layout, and 3D wiring routing.
Comprehensive CAE system for electrical and fluid schematics, 3D panel design, and automated manufacturing outputs.
Integrated electrical schematic and 3D panel modeling tool that syncs with SOLIDWORKS mechanical design.
Intuitive electrical CAD software for schematics, terminal strips, and intelligent panel layouts with strong automation.
Electrical toolset for AutoCAD providing automated wire numbering, component libraries, and panel layouts.
Multi-discipline electrical CAD with Paneldes for 3D routing, wire calculation, and manufacturing reports.
Electrical CAD suite for automation design featuring macros, error checking, and 3D panel visualization.
Danish electrical design software optimized for panel building with intelligent symbols and project navigation.
Advanced tool for complex electrical harnesses, formboard design, and panel integration in aerospace and automotive.
Integrated engineering software for instrumentation, cable management, and panel design in plant projects.
EPLAN Electric P8
enterpriseIndustry-leading software for electrical schematic design, automated panel layout, and 3D wiring routing.
Pro Panel 3D module for fully integrated schematic-to-3D cabinet layout with collision-free virtual wiring and direct manufacturing outputs
EPLAN Electric P8 is a premier CAE (Computer-Aided Engineering) software suite designed for electrical engineers and panel builders, enabling the creation of intelligent schematics, 2D/3D panel layouts, and automated manufacturing documentation. It streamlines the entire process from design to production with features like virtual wiring, error-checked automation, and integration with PLCs and ERP systems. Widely used in automation, machine building, and control cabinet manufacturing, it supports global standards and ensures high-quality, error-free outputs.
Pros
- Extensive component library with over 1 million parts and macro support for rapid design
- Advanced 3D panel layout and automated wire routing for precise manufacturing data
- Seamless integration with ERP/PLM systems and PLC configuration tools
Cons
- Steep learning curve requiring significant training for full proficiency
- High cost, especially for smaller firms without volume licensing
- Resource-intensive, demanding powerful hardware for optimal performance
Best For
Professional electrical engineers and panel builders in large-scale automation and machinery projects requiring precise, standards-compliant designs.
Pricing
Subscription-based pricing starts at around €4,500-€10,000 per user/year depending on modules; perpetual licenses with annual maintenance also available.
Zuken E3.series
enterpriseComprehensive CAE system for electrical and fluid schematics, 3D panel design, and automated manufacturing outputs.
Real-time 3D panel layout with fully automated wire and duct routing that adapts to design changes instantly
Zuken E3.series is a powerful electrical engineering CAD suite, with e3.panel specializing in 2D/3D control panel and cabinet design for panel builders. It automates component placement, wire routing, ducting, and harness manufacturing, while integrating seamlessly with schematic and cable design modules. The software generates accurate BOMs, reports, and production outputs to streamline the entire panel building workflow from concept to fabrication.
Pros
- Seamless integration across schematic, panel layout, and manufacturing outputs
- Advanced 3D routing with collision avoidance and automation
- Robust error-checking and design rule compliance for complex projects
Cons
- Steep learning curve due to extensive features
- High cost unsuitable for small-scale operations
- Requires significant hardware for optimal 3D performance
Best For
Large engineering firms and panel builders handling complex, high-volume electrical control systems in industries like automation and machinery.
Pricing
Enterprise licensing with modular pricing; starts at approximately $15,000 per user annually, plus maintenance fees.
SOLIDWORKS Electrical
enterpriseIntegrated electrical schematic and 3D panel modeling tool that syncs with SOLIDWORKS mechanical design.
Integrated 3D panel layout and automated routing with clash detection in SOLIDWORKS ecosystem
SOLIDWORKS Electrical is a powerful ECAD software suite designed for electrical schematic creation, panel layout, and automated wire routing, specifically tailored for panel building workflows. It offers tight integration with SOLIDWORKS 3D CAD for electromechanical design, enabling precise 3D panel layouts and real-time collaboration. The tool automates manufacturing outputs like BOMs, wire lists, and reports, streamlining production from design to assembly.
Pros
- Seamless 2D/3D integration for comprehensive electromechanical design
- Extensive automated tools for wire routing, numbering, and reporting
- Large manufacturer-certified component library with real-time collaboration
Cons
- Steep learning curve, especially for non-SOLIDWORKS users
- High pricing that may not suit small shops
- Primarily Windows-based with limited cross-platform support
Best For
Mid-to-large engineering teams in manufacturing requiring integrated 2D electrical schematics and 3D panel layouts.
Pricing
Subscription from ~$4,000/year for schematics; full Professional edition ~$7,000+/year; perpetual licenses ~$10,000+ with maintenance.
SEE Electrical
specializedIntuitive electrical CAD software for schematics, terminal strips, and intelligent panel layouts with strong automation.
Advanced 3D panel builder with collision-free automatic routing and real-time manufacturing data export
SEE Electrical by IGE+XAO is a comprehensive CAD software suite designed for electrical schematic design, 3D panel layout, and automated manufacturing outputs, streamlining the entire panel building process from concept to production. It offers intelligent tools for wire routing, component placement, BOM generation, and error checking, ensuring compliance with international standards like IEC and NFPA. The software excels in integrating 2D schematics with 3D cabinet modeling for precise panel fabrication.
Pros
- Seamless integration of schematic design with 3D panel layout and automatic wire routing
- Robust automation for manufacturing outputs like wire lists, drill tables, and BOMs
- Extensive symbol libraries and standards compliance for global use
Cons
- Steep learning curve for beginners due to extensive features
- Primarily Windows-based with limited cross-platform support
- Higher pricing for full modular suite compared to simpler alternatives
Best For
Mid-to-large panel builders and electrical engineering firms needing an end-to-end solution from design to fabrication.
Pricing
Modular perpetual licenses starting at ~€2,000 for basic editions, up to €15,000+ for full Advanced suite with annual maintenance ~20%; subscription options available.
AutoCAD Electrical
enterpriseElectrical toolset for AutoCAD providing automated wire numbering, component libraries, and panel layouts.
Bidirectional schematic-to-panel intelligence that automatically propagates changes and ensures design accuracy
AutoCAD Electrical is a specialized CAD tool from Autodesk designed for electrical engineers to create intelligent schematics, panel layouts, wiring diagrams, and automated reports for control systems. It excels in panel building by enabling precise 2D panel layouts linked bidirectionally to schematics, with automated wire sizing, numbering, and BOM generation. The software supports industry standards and vast component libraries, streamlining design-to-manufacturing workflows.
Pros
- Extensive automation for wire numbering, error checking, and report generation
- Bidirectional linking between schematics and panel layouts for consistency
- Comprehensive symbol libraries and standards compliance (IEC, NFPA, etc.)
Cons
- Steep learning curve due to CAD foundation
- High subscription cost with limited free trial options
- Primarily 2D focused, lacking advanced 3D panel modeling
Best For
Experienced electrical designers and panel builders in industrial settings handling complex control systems who require CAD precision and automation.
Pricing
Annual subscription ~$2,030 USD; available in Autodesk Product Design & Manufacturing Collection for broader access.
Elecdes Design Suite
specializedMulti-discipline electrical CAD with Paneldes for 3D routing, wire calculation, and manufacturing reports.
Paneldes module's advanced 3D duct and cable routing with automatic bend calculations and collision detection
Elecdes Design Suite is a robust CAD-based software suite designed specifically for electrical panel builders, providing intelligent tools for creating schematics, panel layouts, wiring diagrams, and 3D cable routing. It automates tasks like wire numbering, cross-referencing, error checking, and BOM generation to streamline design-to-manufacture workflows. With modules like Elecdes for 2D design and Paneldes for 3D modeling, it supports standards compliance and integration with databases for efficient project management.
Pros
- Comprehensive automation for schematics, layouts, and reporting
- Extensive customizable symbol libraries and standards support
- Powerful 3D cable routing and manufacturing outputs
Cons
- Steep learning curve requiring significant training
- Dated interface compared to modern cloud-based alternatives
- High upfront licensing costs with additional module expenses
Best For
Established engineering firms and panel builders managing complex, high-volume electrical control panel projects that demand precise documentation and automation.
Pricing
Perpetual licenses start at around $4,000-$6,000 per core module, with bundles up to $20,000+ and annual maintenance at 18-20% of license cost.
WSCAD ELECTRIX
specializedElectrical CAD suite for automation design featuring macros, error checking, and 3D panel visualization.
Automated 2D/3D routing with real-time error checking and manufacturing-ready outputs
WSCAD ELECTRIX is a modular electrical CAD software suite specialized in schematic design, 3D panel and cabinet layout, and automated manufacturing outputs for panel builders. It streamlines workflows from engineering to production with features like intelligent routing, error checking, and integration with ERP systems. The software excels in handling complex electrical installations in industries like machine building and plant engineering.
Pros
- Comprehensive automation for wire routing and parts management
- Strong 3D cabinet design with collision detection
- Modular licensing allows scalability for different team sizes
Cons
- Steep learning curve for new users
- Higher pricing for full suite compared to basic alternatives
- Limited third-party integrations outside core electrical ecosystem
Best For
Mid-sized panel builders and electrical engineering firms needing integrated schematic-to-panel automation.
Pricing
Modular subscription starting at €4,500/year per user; full suite around €10,000+ annually.
PCSCHEMATIC Automation
specializedDanish electrical design software optimized for panel building with intelligent symbols and project navigation.
Intelligent symbol library with automatic panel layout generation from schematics
PCSCHEMATIC Automation is an electrical CAD software suite specialized for automation design, enabling users to create intelligent schematics, single-line diagrams, and panel layouts. It automates wire numbering, cross-referencing, BOMs, and terminal plans, facilitating efficient panel building workflows. The tool supports IEC and NFPA standards, with modules for PLC integration and documentation generation, making it suitable for control panel engineering.
Pros
- Seamless integration of schematics with panel layouts and automatic wire/terminal management
- Robust automation for numbering, cross-references, and report generation
- Strong support for international standards and PLC I/O modules
Cons
- Dated interface with a steep learning curve for new users
- Limited 3D panel visualization and routing capabilities
- Modular pricing can become expensive for full functionality
Best For
Mid-sized engineering teams focused on automation and control panel design requiring integrated 2D schematic-to-layout workflows.
Pricing
Perpetual licenses start at ~€2,500 per module; full suite ~€5,000+ with annual maintenance ~20%.
Siemens Capital Electrical Designer
enterpriseAdvanced tool for complex electrical harnesses, formboard design, and panel integration in aerospace and automotive.
Hyper-automation engine that intelligently routes wires, applies design rules, and handles design variants in a unified 3D environment
Siemens Capital Electrical Designer is an advanced electrical CAD software tailored for designing electrical schematics, panel layouts, and wiring systems in complex machinery and automotive applications. It automates design processes with rule-based checks, 3D integration for mechatronics, and generates manufacturing outputs like BOMs and wire lists. As part of Siemens Xcelerator, it supports digital twin creation and seamless data exchange with PLM systems.
Pros
- Powerful automation for error-free designs and variant management
- Integrated 2D/3D panel layout with manufacturing outputs
- Strong ecosystem integration with Siemens PLM and NX tools
Cons
- Steep learning curve for new users
- High enterprise-level pricing
- Overkill for simple panel designs
Best For
Large engineering teams in automotive, aerospace, or heavy machinery needing automated, high-precision electrical panel design.
Pricing
Enterprise subscription or perpetual licensing; pricing available upon request from Siemens, typically starting in the tens of thousands annually.
AVEVA Electrical
enterpriseIntegrated engineering software for instrumentation, cable management, and panel design in plant projects.
Automated bi-directional synchronization between 2D schematics and 3D panel layouts
AVEVA Electrical is a robust engineering software suite tailored for electrical design and panel building, allowing users to create intelligent schematics, automated panel layouts, and wiring diagrams. It excels in generating accurate bills of materials, wire lists, and reports while ensuring compliance with international standards like IEC and NFPA. Integrated within the AVEVA platform, it supports seamless data exchange with 3D modeling tools for comprehensive project workflows in industrial automation.
Pros
- Advanced automation for wire routing, sizing, and panel layout generation
- Strong integration with AVEVA's 3D design and engineering ecosystem
- Comprehensive reporting, BOM, and standards compliance tools
Cons
- Steep learning curve and complex interface for new users
- High licensing costs suitable only for enterprises
- Limited customization options compared to specialized panel tools
Best For
Large industrial engineering teams managing complex, multi-discipline panel building projects.
Pricing
Enterprise subscription model with custom pricing, typically $5,000+ per user annually depending on modules and scale.
Conclusion
The reviewed panel building software showcases diverse strengths, with the top three tools emerging as frontrunners. EPLAN Electric P8 leads with its industry-defining capabilities in electrical schematic design, automated layout, and 3D wiring routing, setting a benchmark for excellence. Zuken E3.series follows with its comprehensive CAE system, while SOLIDWORKS Electrical impresses through seamless integration with mechanical design—each offering distinct advantages for varied professional needs.
For those seeking to optimize panel building processes, EPLAN Electric P8 stands as the top choice. Dive into its robust features to elevate your design, layout, and routing workflows, and experience why it leads the field.
Tools Reviewed
All tools were independently evaluated for this comparison
Referenced in the comparison table and product reviews above.
