Lightning protection calculation software turns geometry, conductor layouts, and earthing parameters into protective-zone results that engineering teams can document and audit. This ranked shortlist targets buyers who need repeatable workflows and data integration with electrical or structural CAD, with the ordering based on calculation coverage, model traceability, and how well each tool fits into existing engineering documentation processes.

Editor’s top 3 picks

Three quick recommendations before you dive into the full comparison below — each one leads on a different dimension.

Editor pick
1

ELCAD: Lightning Protection

Calculation definition templates that standardize protection parameters across multiple project reruns.

Built for fits when teams need repeatable lightning calculations from consistent project data and governed setups..

2

EPLAN

Editor pick

Project-template driven calculation parameter provisioning with structured report outputs.

Built for fits when engineering teams need governed lightning calculations embedded in project workflows..

3

AutoCAD Electrical

Editor pick

Project-level tag and attribute management that drives consistent component labeling across electrical drawings.

Built for fits when electrical teams automate lightning documentation generation from tagged CAD projects..
