Pro Landscape is the best choice for teams that need revision-controlled, dimensioned fence drawings straight from field measurements, while Planner 5D fits homeowners and small contractors who want quick fence design iterations with exportable visuals, and if you’re budget-tight ArcSite is a solid mobile CAD-first fallback.
Editor’s top 3 picks
Three quick recommendations before you dive into the full comparison below — each one leads on a different dimension.
Pro Landscape
Bidirectional linkage between fence geometry edits and updated dimensions across exported drawing sets.
Built for fits when teams need revision-controlled, dimensioned fence drawings from field measurements..
FenceEstimator
Editor pickAutomatic fence element layout logic that keeps dimensions aligned while updating revisions across the drawing set.
Built for fits when contractors need repeatable fence plans and revision-ready drawing exports without CAD overhead..
Planner 5D
Editor pickDrag-to-design fence layout with real-time 3D rendering for rapid gate, post, and segment edits.
Built for fits when homeowners and small contractors need quick fence design revisions with exportable visuals..
Related reading
Comparison Table
Pro Landscape
vertical specialistPro Landscape combines landscape design, photo imaging, CAD, and estimating features for outdoor projects.
Bidirectional linkage between fence geometry edits and updated dimensions across exported drawing sets.
Pro Landscape supports a fence drafting workflow that starts from site context and ends with dimensioned output for construction detail sheets. Property-line tracing and setback measurement help standardize how the fence aligns to parcel boundaries before panel layout is finalized. Fence height annotation and gate placement tools keep the drawing tied to build constraints instead of sketch-only intent.
A practical tradeoff is that advanced terrain slope modeling and grade transition require disciplined input for consistent fence elevation drawings. Pro Landscape fits best when field measurements arrive in batches and revisions must stay synchronized across linear-footage totals and drawing dimensions.
- +Automates panel layout and linear-footage estimation from fence geometry
- +Supports parcel boundary import to accelerate starting conditions
- +Keeps gate placement and corner post layout consistent across edits
- +Exports CAD and PDF drawing sets for contractor handoff
- –Advanced grade transition works best with carefully entered slope inputs
- –Terrain-linked elevation drawing requires extra review on complex lots
- –DXF import can need cleanup when source drawings use mismatched layers
- –Mobile field measurement coverage is limited compared with full desktop drafting
Landscape design teams
Create permit-ready fence drawing sets
Faster review cycles
Contractors
Convert takeoffs into build-ready markup
Reduced field rework
Show 1 more scenario
Small planning departments
Standardize boundary and setback alignment
More predictable submissions
Apply property-line tracing and setback measurement rules to keep fence placement consistent across projects.
Best for: Fits when teams need revision-controlled, dimensioned fence drawings from field measurements.
FenceEstimator
vertical specialistFence estimating software with diagramming and material calculation.
Automatic fence element layout logic that keeps dimensions aligned while updating revisions across the drawing set.
FenceEstimator fits teams that need repeatable fence plan outputs with consistent dimensions rather than freestyle drafting. The core workflow centers on placing posts and fence elements, then generating a drawing set suitable for customer review and field handoff. The tool’s strongest fit signals come from its emphasis on construction-oriented layouts, revision cycles, and documentation exports.
A tradeoff is that FenceEstimator is less suited to highly customized CAD detailing when drawing requirements exceed its fence-first geometry assumptions. It works best when field measurements or parcel information are already structured for linear fence layouts and the deliverable is a clear plan plus a count-based estimate.
- +Fence-first drawing workflow keeps posts, rails, and panels consistent
- +Exports support practical sharing for customer review and installer handoff
- +Revision-friendly layout updates reduce rework between plan versions
- +Gate and end-post planning is built into the layout process
- –CAD-style detailing beyond fence geometry requires separate drafting work
- –Advanced site modeling needs more manual setup than fence placement
Contractors and installers
Turn field notes into plan drawings
Faster plan handoff
Designers supporting sales
Revise fence concepts for customers
Fewer re-draw cycles
Show 2 more scenarios
Estimators
Compute quantities from a consistent layout
Cleaner material estimates
Use the fence element breakdown to align takeoffs with the same plan that customers review.
Project managers
Share drawings with crews
Reduced schedule confusion
Export plan outputs that crews can use as the reference during installation and revisions.
Best for: Fits when contractors need repeatable fence plans and revision-ready drawing exports without CAD overhead.
Planner 5D
SMBPlanner 5D provides browser-based 2D and 3D tools for property and outdoor layout concepts.
Drag-to-design fence layout with real-time 3D rendering for rapid gate, post, and segment edits.
Planner 5D lets users place fence segments, posts, and gates in a guided modeling flow and view results in both 2D and 3D views. Fence annotation features are suited for dimensioned site-plan communication and clearer construction instructions. The software can bring in base geometry from external formats and export diagrams for collaboration. For workflows that need repeated design revisions, the browser interaction model reduces friction compared with desktop-only CAD tools.
A key tradeoff is that Planner 5D focuses on fence layout and visualization rather than deep CAD parametric detailing or drafting standards control. Designs with complex geometry and strict drawing set conventions can require extra cleanup after import or before export. It fits best when a homeowner or contractor needs quick fence elevation drawing updates and a shared visual reference during selections and revisions.
- +Browser-based fence layout with instant 2D and 3D feedback
- +Gate and post placement tools support common residential fence patterns
- +Fence height and layout annotations are built into the modeling workflow
- +Export paths support sharing for contractor review without extra modeling passes
- –CAD export can require cleanup for strict dimensioning workflows
- –Terrain and grade transitions are limited for highly irregular sites
- –Automation for panel layout calculations is not as configurable as CAD plugins
- –Import fidelity depends on source geometry quality and formatting
Homeowner design workflow
Iterate fence height and gate placement
Faster design signoff
Small contractor collaboration
Send revision-ready fence layouts
Fewer rework loops
Show 2 more scenarios
Remodeling project coordinators
Coordinate fence plan with site baselines
Clearer site placement
Users import existing geometry and place fence elements to match the current site reference.
Design sales reps
Create meeting-ready fence elevations
Higher proposal clarity
The tool generates fence visualization outputs suitable for client review during selection calls.
Best for: Fits when homeowners and small contractors need quick fence design revisions with exportable visuals.
BidSolid
vertical specialistFence industry software for estimating, drawing, and proposal generation.
Panel-first drawing workflow that generates gate and post placement details tied to a consistent fence elevation output.
BidSolid is a fence drawing software focused on turning site measurements into permit-ready fence drawing sets. It supports 2D fence layout creation with panel and gate placement workflows, then carries that geometry into 3D fence visualization and clear elevations for review. The core draw output is designed for construction documentation needs like dimensioned site plans and construction detail sheets.
- +Fast panel layout workflow for repeatable fence runs
- +3D fence visualization tied to the same layout geometry
- +Gate placement tools for dimensioned construction drawings
- +Export outputs suited for sharing across jobsite stakeholders
- –DXF import coverage can fall short for complex CAD source geometry
- –Fewer automation options than workflow-centric CAD ecosystems
- –Limited control for highly custom construction detail conventions
- –Terrain slope modeling depth may not match heavy grading requirements
Best for: Fits when fence installers and small design teams need repeatable 2D layouts that produce usable elevations quickly.
SmartDraw
SMBSmartDraw provides diagramming and drawing tools for layouts, site plans, and property illustrations.
Symbol template library for fence layouts that keeps corner, end-post, and gate placement consistent across revisions.
SmartDraw produces 2D fence layout drawings using template objects for posts, panels, and gates, which reduces time spent redrawing standard fence components.
Export formats include PDF and DXF, which supports construction detail sheet workflows and CAD file export for secondary detailing.
Revision workflows support image markup and iterative updates on the same plan package, which helps coordinate installer feedback with homeowner design workflow changes.
- +Template-driven fence elements speed panel and post layout drafting
- +DXF export supports CAD-based downstream detailing workflows
- +PDF export supports permit drawing set handoff without extra formatting work
- +Reusable styles keep gate and post symbols consistent across revisions
- –Parcel boundary import and property-line tracing are limited compared to CAD-first tools
- –Terrain slope modeling and grade transition controls are not designed for survey-grade elevations
- –Automation is mostly template and macro based rather than a full programmable API surface
- –Post spacing calculation and material takeoff remain manual for larger projects
Best for: Fits when fence plans need consistent symbols and quick PDF or DXF deliverables for contractor collaboration.
ArcSite
SMBArcSite provides mobile CAD drawing, field measurement, estimating, and proposal tools.
Integrated fence elevation drawing generation tied to post spacing and panel layout rules.
ArcSite is a fence drawing tool aimed at producing permit-ready site-plan graphics from traced property geometry. It focuses on fence elevation drawing outputs with layout automation for posts, panels, and gates tied to distance-based measurements.
