Grounding in PSCAD
Grounding results compute from PSCAD circuit excitation so earth potential rise and safety voltages align with the simulated fault event.
Best for: Fits when grounding studies must match PSCAD fault simulations and safety voltage outcomes.
PowerFactory
Editor pickTight coupling between system fault conditions and earthing safety checks inside the same project study workflow.
Best for: Fits when earthing performance must be derived from real network fault scenarios in one model.
CYMGRD
Editor pickGrounding-grid design workflow keeps electrode and buried conductor configuration tied to safety check outputs.
Best for: Fits when teams iterate grounding grid designs from CAD layouts and need consistent touch and step checks.
Comparison Table
Grounding in PSCAD
enterpriseElectromagnetic transient simulation software from Manitoba Hydro International that supports grounding system modeling and fault analysis.
Grounding results compute from PSCAD circuit excitation so earth potential rise and safety voltages align with the simulated fault event.
Grounding in PSCAD is centered on modeling buried conductor layouts and calculating earth potential rise and fault current distribution using the same PSCAD project structure as the rest of the system study. The tool workflow connects grounding geometry to electrical excitation so results reflect the studied fault scenario rather than a generic worst-case model. It also supports engineering checks that relate conductor configuration to personnel safety metrics through touch and step voltage evaluation.
A tradeoff appears in setup effort because correct results depend on consistent model definition for soil layers, electrode geometry, and the fault current path represented in PSCAD. It fits best when grounding studies already live inside a PSCAD system model, such as substation grounding connected to switching and protection events. It fits less when a standalone grounding report with minimal simulation coupling is the only requirement.
- +Tight coupling between grounding geometry and PSCAD fault-driven excitation
- +Earth potential rise and safety voltage results derived from the same scenario
- +Supports multilayer soil resistivity modeling for more realistic electrode behavior
- +Produces grid conductor sizing inputs tied to simulation results
- –Requires disciplined PSCAD model setup for soil, geometry, and fault path consistency
- –Grid-only studies without electrical coupling can feel heavier than dedicated tools
- –Post-processing and report formatting can require additional engineering steps
- –Geometry import workflows are not the primary strength compared with CAD-first tools
Power system studies teams
Substation grounding tied to faults
Scenario-consistent safety voltages
Protection and commissioning engineers
Touch and step voltage verification
Actionable safety check evidence
Show 1 more scenario
Transmission grounding designers
Multilayer soil modeling for grids
More realistic earth behavior
Use soil layer definitions to refine ground behavior for grid and electrode layouts.
Best for: Fits when grounding studies must match PSCAD fault simulations and safety voltage outcomes.
PowerFactory
enterprisePowerFactory includes grounding-system studies for power networks, substations, and fault-current analysis.
Tight coupling between system fault conditions and earthing safety checks inside the same project study workflow.
For earthing grid design, PowerFactory uses a study-driven workflow where grid geometry and soil parameters feed earth potential rise and electrode effectiveness calculations tied to network fault conditions. The environment can import and export geometry formats such as DXF and enables structured handling of buried conductor layouts within the electrical study context. For fault and thermal effects on conductors, the grounding results connect to the broader system so grounding can be assessed under actual network switching and operating states.
A key tradeoff is that grounding-only teams may find the workflow heavier than grid-only tools because geometry preparation and electrical model alignment are needed to get consistent results. PowerFactory fits best when the same team must translate network topology and operating scenarios into protection-relevant grounding performance without exporting data into separate tools.
- +Grounding checks stay synchronized with network fault studies
- +Supports automated scenario runs for repeated grounding iterations
- +DXF-based geometry exchange supports grid layout reuse
- +Multilayer soil inputs enable more detailed soil resistivity modeling
- –Earthing-focused teams may spend extra time aligning electrical and grid models
- –Geometry edits can be slower than dedicated grid layout tools
- –Grounding results depend on accurate network and operating-state setup
- –Advanced workflows often require careful study configuration discipline
Protection engineers
Assess touch voltage under switching scenarios
Fewer mismatched grounding assumptions
Substation grounding teams
Iterate grid layout with shared geometry
Faster geometry rework cycles
Show 2 more scenarios
Electrical model integrators
Automate repeatable grounding scenarios
Higher iteration throughput
Scripting and repeatable study configuration support batch runs across network operating states and grid variants.
Consulting engineers
Standardize earthing studies across projects
More consistent client reports
Study setups can be kept consistent so grounding outputs follow the same engineering assumptions across deliverables.
Best for: Fits when earthing performance must be derived from real network fault scenarios in one model.
CYMGRD
enterpriseCYMGRD performs grounding-grid analysis for substations and electrical power installations.
Grounding-grid design workflow keeps electrode and buried conductor configuration tied to safety check outputs.
CYMGRD targets engineers who need repeatable grounding system design steps, from buried conductor layout definition through evaluation outputs for safety criteria. The workflow is structured around grounding grid modeling rather than treating earthing as a one-off calculation. CAD import and export help keep conductor routes aligned with site layouts when projects use survey drawings and GIS-derived backgrounds. The integration angle matters most on projects where design changes trigger rechecks without redoing the entire model.
A key tradeoff is that CYMGRD’s workflow depth is strongest for grounding grid studies, while broader soil analysis and advanced multiphysics simulation setups are not the focus compared with general-purpose simulation suites. CYMGRD fits situations where protection and grounding design deliverables must stay consistent across revisions for substations and similar facilities. It is a practical choice when engineering teams want faster iteration on conductor sizing and configuration changes rather than deep research-grade modeling variants.
- +Grounding-grid workflow aligns with substation earth electrode design tasks
- +CAD import and export reduces manual redraw during layout revisions
- +Outputs support safety checks for step and touch voltage comparisons
- +Configurable buried conductor layout supports iterative conductor route changes
- –Less suited for multiphysics studies outside grounding grid scope
- –Modeling accuracy depends on disciplined input preparation from site drawings
- –Complex projects can require more time to validate geometry and boundaries
- –Automation depth is limited for fully scripted, end-to-end batch studies
Substation grounding engineers
Design electrode and grid safety checks
Revised grid meets safety targets
Industrial electrical design teams
Update earthing layout from site drawings
Faster turnaround across revisions
Show 1 more scenario
Consulting engineering project leads
Standardize grounding deliverable generation
More consistent engineering outputs
Use a structured grid workflow to maintain consistent design assumptions across projects.
Best for: Fits when teams iterate grounding grid designs from CAD layouts and need consistent touch and step checks.
Earthing Calculator
SMBCloud-based earthing and grounding design tool covering grid resistance, touch voltage, step voltage, and ground potential rise calculations.
Input-to-result grounding calculators that translate soil resistivity testing assumptions into IEEE 80 style safety metrics.
Earthing Calculator on elek.com focuses on grounding system design workflows that convert soil and earth electrode inputs into earth safety checks for step and touch conditions.
- +Grounding checks driven directly from measured or assumed soil inputs
- +Built for repeatable electrode and grid sizing iterations
- +Safety-metric oriented outputs tied to IEEE 80 style workflows
- +Import and export of study inputs and results supports standard documentation
- –Finite-element analysis depth for multilayer and complex geometries is limited
- –Automation for batch parametric studies requires manual control for many runs
Best for: Fits when teams need fast, repeatable earthing grid and electrode studies with standards-based safety checks.
XGSLab
vertical specialistXGSLab designs and analyzes grounding systems, earthing grids, cables, and lightning protection systems.
End-to-end earthing study linkage from electrode and grid geometry to touch and step performance verification within one workflow.
XGSLab performs earthing and grounding system design calculations with a workflow that links electrode and grid geometry inputs to verification outputs. The software supports soil resistivity modeling and standard earthing performance checks tied to touch and step voltage limits. It also focuses on conductor and electrode arrangement modeling for grounding system design and allows output for documentation via exported study results.
- +Tight coupling between geometry inputs and earthing limit outputs
- +Soil resistivity modeling supports multilayer study workflows
- +Conductor and electrode layout modeling supports grid and rod combinations
- +Exported study outputs support documentation and handoff
- –Limited automation for batch studies across many design variants
- –CAD import and GIS workflows are not a core part of the design loop
- –Advanced finite-element modeling is not its primary analysis path
- –Governance controls for multi-user admin workflows are minimal
Best for: Fits when engineering teams need repeatable earthing grid and electrode sizing with soil modeling and clear verification reports.
CDEGS
vertical specialistCDEGS analyzes grounding systems, soil structures, electromagnetic interference, and step-and-touch voltages.
Integrated grounding study engine that keeps earth potential rise and touch and step results tied to the same conductor-and-soil model across scenarios.
CDEGS from sestech.com fits engineering teams that need repeatable grounding system design and study workflows for substations, industrial sites, and telecom facilities. The software supports soil resistivity modeling, earthing grid design, and protection-relevant calculations such as earth potential rise and conductor behavior under fault conditions.
- +Strong grounding study workflow from geometry to EPR and safety quantities
- +Well-developed soil modeling for scenarios that change with multilayer assumptions
- +CAD import and structured report outputs for study documentation handoffs
- +Scenario comparisons support iteration without rebuilding the entire model
- –Configuration effort increases when mixing multilayer soil, electrodes, and grid variants
- –Limited automation surface for external pipeline execution without manual steps
- –Model validation requires careful checking of geometry units, boundaries, and meshing inputs
- –API and extensibility options are not exposed at the same depth as developer-first tools
Best for: Fits when grounding studies need consistent scenario iteration from grid geometry and soil assumptions.
ETAP Ground Grid
enterpriseETAP Ground Grid models grounding grids and calculates current distribution, touch voltage, and step voltage.
Grounding studies generated in the same ETAP environment as electrical studies to keep inputs and artifacts aligned.
ETAP Ground Grid differentiates itself by pairing earthing grid modeling with ETAP’s wider electrical design workflow, so grounding results can stay consistent with system study assumptions. The software supports grid and electrode layout definition, soil resistivity input for modeling, and calculation of earth potential rise and related safety quantities used in grounding design.
- +Ties grounding design outputs to ETAP network study data for consistent assumptions
- +Supports buried grid and electrode geometry setup within one modeling workflow
- +Provides engineering outputs aligned to touch and step voltage safety evaluation needs
- +Geometry and results transfer supports CAD-style workflows through import and export
- –Automation and API surface is limited compared with tools that expose full programmatic study runs
- –Model setup can require careful soil input selection to avoid misleading safety results
- –Complex substation cases can produce dense inputs that are harder to review than in lightweight GUIs
- –Finite-element style modeling workflows are not the strongest path compared with specialist solvers
Best for: Fits when ETAP-centered teams need grounding and safety studies tied to electrical system assumptions.
Conclusion
After evaluating 7 earthing design software, Grounding in PSCAD stands out as our overall top pick — it scored highest across our combined criteria of features, ease of use, and value, which is why it sits at #1 in the rankings above.
Use the comparison table and detailed reviews above to validate the fit against your own requirements before committing to a tool.
How to Choose the Right Earthing Design Software
Earthing design software supports grounding grid and protection studies by turning conductor geometry and soil assumptions into safety quantities like earth potential rise and touch and step voltages. This buyer’s guide covers Grounding in PSCAD, PowerFactory, CYMGRD, Earthing Calculator, XGSLab, CDEGS, and ETAP Ground Grid based on how each tool couples grounding checks to the surrounding study workflow.
The comparison emphasizes integration depth, grounding-specific automation and iteration behavior, and the practical impact of scenario consistency across conductor and soil inputs. Grounding in PSCAD leads for cases where grounding results must come from the same fault excitation used in PSCAD so safety voltages and electrical events stay aligned.
Earthing Design Software for grounding grids, safety voltage checks, and soil resistivity modeling
Earthing design software takes grounding geometry such as buried conductor layouts and earth electrode configurations, combines it with soil resistivity assumptions and multilayer models, and computes grounding performance like earth potential rise plus step and touch voltage metrics. Tools in this list differ in how directly they connect those grounding outputs to the electrical or fault scenario that defines the test conditions.
Grounding in PSCAD computes grounding results from PSCAD circuit excitation, so earth potential rise and safety voltages follow the same simulated fault event. PowerFactory keeps grounding safety checks synchronized with system fault studies inside the same project workflow, while CDEGS ties earth potential rise and safety quantities to a consistent conductor-and-soil model across scenarios.
Earthing design fit checks: scenario coupling, soil modeling, and iteration control
Earthing design software earns its place when grounding safety quantities come from a conductor-and-soil model that stays consistent with the fault or network scenario that defines the test conditions. Grounding in PSCAD computes grounding results from PSCAD circuit excitation so earth potential rise and safety voltages align with the simulated fault event.
The practical difference across tools shows up when teams iterate designs across geometry edits and soil assumptions. PowerFactory keeps earthing safety checks synchronized with network fault studies inside the same project workflow, while CDEGS ties earth potential rise and touch and step results to the same conductor-and-soil model across scenarios.
Fault-driven grounding scenario coupling
Grounding in PSCAD derives earth potential rise and safety voltages from PSCAD circuit excitation tied to the same fault event. PowerFactory keeps grounding checks synchronized with system fault conditions in the same project study workflow.
Geometry to safety-quantity linkage inside one workflow
CYMGRD keeps electrode and buried conductor configuration tied to safety check outputs in its grounding-grid design workflow. XGSLab links electrode and grid geometry to touch and step performance verification within one workflow, so results follow geometry changes.
Multilayer soil modeling depth for scenario variants
CDEGS provides well-developed soil modeling for scenarios that change with multilayer assumptions while keeping results tied to the same conductor-and-soil model. XGSLab includes soil resistivity modeling that supports multilayer study workflows, but its batch automation surface is limited.
Standards-based safety metrics from measured or assumed soil inputs
Earthing Calculator translates soil resistivity testing assumptions into IEEE 80 style safety metrics for repeatable electrode and grid sizing iterations. This approach is faster for standard safety checks but it limits finite-element depth for complex geometries.
Integration of grounding work with electrical studies artifacts
ETAP Ground Grid generates grounding studies in the same ETAP environment as electrical studies so inputs and artifacts stay aligned. It supports buried grid and electrode geometry setup within one modeling workflow for ETAP-centered teams.
CAD import and export to reduce redesign friction
CYMGRD uses CAD import and export to reduce manual redraw during layout revisions for grounding-grid iterations. XGSLab focuses on the earthing study loop and keeps CAD and GIS workflows from being a core part of that design loop.
Select based on what defines your acceptance case: excitation coupling, scenario iteration, or fast standard checks
The first decision is whether the grounding acceptance case depends on a specific fault event that already exists in a system model. If safety voltages must follow the same simulated fault excitation, Grounding in PSCAD and PowerFactory provide the strongest scenario coupling.
The second decision is whether the grounding workflow must stay grounded in grounding-grid design tasks that start from CAD layouts and evolve through geometry edits. CYMGRD supports that grounding-grid design loop with CAD import and export, while XGSLab emphasizes repeatable geometry-to-verification linkage with multilayer soil modeling.
Tie safety quantities to the same fault event that drives electrical conditions
Choose Grounding in PSCAD when the grounding results must compute from PSCAD circuit excitation so earth potential rise and safety voltages align with the simulated fault event. Choose PowerFactory when earthing performance must be derived from real network fault scenarios in one model so grounding checks remain synchronized with network fault studies.
Run grounding as a geometry-driven design loop with consistent electrodes and grid
Choose CYMGRD when teams iterate grounding-grid designs from CAD layouts and want electrode and buried conductor configuration tied to touch and step safety outputs. Choose XGSLab when repeatable electrode and grid sizing must link directly to touch and step verification with multilayer soil modeling in the same workflow.
Adjust soil assumptions across scenarios with a conductor-and-soil model that stays unified
Choose CDEGS when multilayer soil scenario changes must remain tied to the same conductor-and-soil model across EPR and safety checks. Choose XGSLab when soil resistivity modeling with multilayer support is required but CAD and GIS integration is not the primary design loop.
Use standard safety metrics when the deliverable is fast electrode and grid sizing from soil inputs
Choose Earthing Calculator when measured or assumed soil inputs must translate quickly into IEEE 80 style safety metrics for repeatable sizing iterations. Expect limited finite-element analysis depth for multilayer and complex geometries, so use it when geometries are straightforward or when time constraints dominate.
Stay inside an electrical-study environment where grounding artifacts must follow system assumptions
Choose ETAP Ground Grid when ETAP-centered teams need grounding studies generated in the same ETAP environment as electrical studies. Use it to keep inputs and artifacts aligned with buried grid and electrode geometry setup, while planning for limited automation and API surface relative to more programmatic tools.
Teams that get value from scenario-coupled earthing workflows and geometry-to-safety iteration
Earthing design software fits organizations that must justify safety voltages and earth potential rise as consequences of both conductor layout and the scenario that defines test conditions. The best fit depends on whether grounding results are required to follow PSCAD or network fault studies, or whether grounding checks are mainly driven by electrode and grid sizing from soil inputs.
Tools in this guide separate those needs through different workflow couplings. Grounding in PSCAD and PowerFactory align grounding with fault simulations, while CYMGRD and XGSLab emphasize grounding-grid iteration and verification from geometry and soil models.
Electrical protection and network studies teams that already model faults
Grounding in PSCAD and PowerFactory keep grounding safety outcomes tied to the same fault or network scenario used in electrical studies, so earth potential rise and safety voltages stay aligned with the simulated events.
Substation earthworks design teams iterating from CAD layouts
CYMGRD links electrode and buried conductor configuration to grounding-grid safety checks and supports CAD import and export to reduce manual redraw during layout revisions.
Earthing engineering teams that vary multilayer soil assumptions across scenarios
CDEGS keeps touch and step results and earth potential rise tied to the same conductor-and-soil model across multilayer scenario changes, and XGSLab supports multilayer soil modeling inside its geometry-to-verification workflow.
Engineering groups focused on repeatable standard safety calculations from soil inputs
Earthing Calculator translates soil resistivity testing assumptions into IEEE 80 style safety metrics for fast electrode and grid sizing iterations.
Common Earthing Design Software pitfalls that break traceability between geometry, soil, and test conditions
A recurring failure mode is separating grounding safety outputs from the scenario that defines the test conditions. Grounding in PSCAD and PowerFactory reduce this risk by computing grounding results from the same simulated fault excitation or by keeping grounding checks synchronized with network fault studies.
Another failure mode is building a grounding model that looks correct in CAD but relies on inconsistent soil or electrode inputs, which makes touch and step results hard to reproduce. CDEGS and XGSLab can model multilayer scenarios, while Earthing Calculator limits finite-element depth, so teams must match tool depth to geometry and soil complexity.
Building grounding safety outputs from geometry edits while keeping the electrical or fault scenario fixed
Use Grounding in PSCAD when earth potential rise and safety voltages must compute from PSCAD circuit excitation, and use PowerFactory when grounding checks must remain synchronized with network fault scenarios.
Assuming multilayer accuracy is automatic without aligning soil modeling assumptions across scenarios
Use CDEGS when multilayer soil scenario changes must remain tied to the same conductor-and-soil model, and plan for configuration effort when mixing multilayer soil, electrodes, and grid variants.
Using fast standard calculators for complex geometries that require deeper finite-element treatment
Choose Earthing Calculator for repeatable IEEE 80 style safety metrics driven by soil inputs, and avoid it for multilayer and complex geometries when finite-element analysis depth becomes the limiting factor.
Treating CAD workflow as an afterthought in a geometry iteration loop
Choose CYMGRD when grounding-grid iterations must flow from CAD import and export, and avoid expecting XGSLab to supply CAD or GIS workflows as a core part of the design loop.
How We Selected and Ranked These Tools
We evaluated earthing design workflows across grounding geometry to safety-quantity coupling, then assessed how fault or network scenario context stays synchronized with earth potential rise and touch and step results. Features received 40% weight because grounding acceptance depends on the study engine workflow and scenario iteration behavior.
Ease and value received 30% each based on how quickly teams can repeat grounding iterations without manual reconciliation between geometry inputs and safety checks. Grounding in PSCAD ranked first because grounding results compute from PSCAD circuit excitation so earth potential rise and safety voltages align with the simulated fault event, which keeps traceability tight across the electrical scenario and grounding safety outputs.
Frequently Asked Questions About Earthing Design Software
How does grounding results coupling differ between ETAP Ground Grid and XGSLab for fault studies?
Which tool best supports repeatable scenario iteration when soil and geometry inputs change?
When should grounding work be modeled inside a circuit simulation project instead of a standalone grid study?
How do CYMGRD and CDEGS handle CAD-oriented collaboration for grounding-grid layouts?
What data model issues commonly break when moving results from Earthing Calculator to ETAP Ground Grid?
How does PowerFactory’s workflow affect fault current distribution assumptions compared with CDEGS?
Which tool makes it easiest to trace touch and step voltage outputs back to the exact electrode and buried conductor geometry?
What breaks if the soil resistivity modeling basis is inconsistent across tools in a multi-team study?
How do integrations and automation capabilities differ between ETAP Ground Grid and Grounding in PSCAD?
Where does performance validation tend to fall short when using calculator-style workflows in Earthing Calculator for protection-critical grounding?
Tools reviewed
Primary sources checked during evaluation.
Referenced in the comparison table and product reviews above.
- Construction InfrastructureTop 10 Best Earthing System Design Software of 2026
- Construction InfrastructureTop 10 Best Earthing Calculation Software of 2026
- Construction InfrastructureTop 10 Best Earthing Software of 2026
- Construction InfrastructureTop 10 Best Building Electrical Design Software of 2026
- Construction InfrastructureTop 10 Best Electrical Engineering Design Software of 2026
Keep exploring
Comparing two specific tools?
Software Alternatives
See head-to-head software comparisons with feature breakdowns, pricing, and our recommendation for each use case.
Explore software alternatives→In this category
Construction Infrastructure alternatives
See side-by-side comparisons of construction infrastructure tools and pick the right one for your stack.
Compare construction infrastructure tools→
